Product Description
Cement Valves 400mm Alloy Cement Pneumatic Powder Butterfly Valve
Design Feature
High sealing, no leakage with stronger, longer lasting blanket seals |
Easy installation, no constrain angle |
16Mo3 steel for plate, import from German, no deformation ≤600°C |
45# steel for screw, brass for screw assembly, avoid adhesion |
Square steel in one side of the gate path, rollers in another side, low friction & avoid dust stratification |
Difunctional cylinder device, Schneider limit switch , smooth, low vibration & noise |
| Accurate loading and metering |
| Welded housing for higher durability and better dependability ZGMn13-2 material for cutout, high hot and wear resistant |
| Electric controller with 4-20mA input signal |
| The compact modular design with exchangeable cassette-type |
| Sealing ensures easy maintenance at low maintenance costs |
| Low noise & vibration,long service life |
Outline Dimension Drawing
| SIZE | AXA | B | N×C | D | E | H |
| 400 | 400×400 | 400 | 4×117 | 516 | 586 | 1798 |
| 500 | 500×500 | 500 | 4×142 | 616 | 686 | 2108 |
| 600 | 600×600 | 600 | 4×167 | 716 | 786 | 2508 |
| 700 | 700×700 | 700 | 6×130 | 850 | 892 | 2908 |
| 800 | 800×800 | 800 | 8×110 | 950 | 992 | 3308 |
| 900 | 900×900 | 900 | 8×123 | 1050 | 1092 | 3708 |
| 1000 | 1000×1000 | 1000 | 9×120 | 1150 | 1192 | 4108 |
Specifications
| Spec | Unit | B200 | B250 | B300 | B400 | B500 | B630 | |
| Items | ||||||||
| Valve body | Flow scope | m3/h | 40-260 | 60-360 | 70-480 | 90-650 | 110-820 | 140-1450 |
| Angle θ | ° | 71 | 71 | 71 | 71 | 71 | 71 | |
| Diameter Width | mm | 200 | 250 | 300 | 346 | 346 | 346 | |
| Diameter Length | mm | 346 | 346 | 346 | 400 | 500 | 600 | |
| Circulation Area | m2 | 0.012 | 0.014 | 0.017 | 0.026 | 0.032 | 0.051 | |
| Electric actuator | Model BERNAED | ASP | ASP | AS50 | AS100 | AS100 | BS200 | |
| Maximum torque | 250 | 250 | 500 | 1000 | 1000 | 2000 | ||
| Input, output signal mA | 420 | |||||||
| Angle θ° | 90 | |||||||
| Input power V | 380 | |||||||
| Flow properties | Percentage | |||||||
| Working temperature | ≤120 | |||||||
| Material | PET5-6 | PET5-6 | PET5-6 | PET5-6 | PET5-6 | |||
| Permeable layer | Ventilation Area | m2 | 0.057 | 0.064 | 0.07 | 0.09 | 0.09 | |
| Consumption | m3/min | 0.5 | 0.5 | 0.5 | 0.5 | 0.5 | ||
